| Conditon: | New | Weight: | 75kg |
|---|---|---|---|
| Motor Power: | 2.2kw | Impactl Force: | 17kn |
| Advance Speed: | 10-13m/min | Warranty: | 12 Month |
| High Light: | vertical rammer compactor,upright rammer compactor |
||
1.No need to mix fuel and oil, easy starting, low-noise operation and low maintenance ;
2.Heavy shock mount system to reduce hand-arm vibration and improve comfort;
3.Rammer shoe made of steel plate with wooden insert offers economical usage;
4.Special protective frame for engine, prevents any possible damage on tough job site.
Technical Specification:
| Model | Motor | Power | Force | Rate | Speed | Jump Height | Plate Size | Weight |
| v/hz | kw | kN | time/min | m/min | mm | mm | kg | |
| HCD70 | 380/50 | 2.2 | 17 | 600-700 | 8-12 | 55-70 | 275*300 | 75 |
| HCD70B | 380/50 | 2.5 | 16 | 600-700 | 8-12 | 45-65 | 250*290 | 75 |
| HCD100 | 380/50 | 3 | 20 | 600-700 | 8-12 | 55-70 | 340*285 | 90 |
