Standing On Electric Stacker Electronic Power Steering 1-2t Up To 3.6m
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Power Souce | AC Motor | Max. Lifting Height | 1.6m~3.6m |
|---|---|---|---|
| Fork Width | 570/695 Mm | Rated Loading Capacity | 1t & 1.6t & 2t |
| Fork Size | 60/180/1150 S/e/l (mm) | Type Of Steering | Electric |
| High Light | Electronic power Steering Electric stacker,Standing on Electric stacker,1-2t Electric stacker |
||
Product Description
PRODUCT FEATURES
1.High power MOSFETS driver. High frequency, efficient, quiet, step less speed regulation and reverse braking function;
2. Advanced vertical AC drive system, motor can get more energy and greater brake torque, more powerful and efficient, accelerated performance is better;
3.The whole series is configured with a special gantry steel, great plasticity, strong anti-bending ability; high structural stability;
4.The whole series equipped with standard steering system, the assisted power is responsive and the handle is easy to operate；
5.The number of components required for the AC motor is little. There are no fragile components that need to be replaced regularly, almost no maintenance, it is more efficient and durable；
6.Equipped with side pull battery configuration, battery replacement is faster and more convenient , easier for continuous operation ,greatly improve work efficiency;
7.The standard configuration is lifting limit, when the fork rises to the top, the system automatically cuts off the uplink power supply, smooth parking, effective prevent the occurrence of "roof falling" accidents；
| Model | CL1016GA | CL1030GA | CL036GA | CL1616GA | CL1630GA | CL636GA | CL2016GA | CL2030GA | CL2036GA | |
| Power unit | Electric | |||||||||
| Operation | Standing on | |||||||||
| Rated traction weight |
Q (t) | 1 | 1.6 | 2 | ||||||
| Load centre | c (mm) | 600 | ||||||||
| Axle centre to fork face |
x (mm) | 673 | ||||||||
| Wheel base | y (mm) | 1332 | ||||||||
| Service weight with battery |
kg | 920 | 1030 | 1070 | 940 | 1065 | 1105 | 960 | 1090 | 1135 |
| Wheels type | PU | |||||||||
| Driving wheel size | Φ×w(mm) | Φ250×75 | ||||||||
| Bearing wheel size | Φ×w(mm) | Φ80×70 | ||||||||
| additional wheels (dimensions) |
Φ×w(mm) | Φ115×55 | ||||||||
| Wheels, number front/rear (x = driven) |
1x+2/4 | |||||||||
| Track width | b10 (mm) | 580 | ||||||||
| Track width | b11 (mm) | 515/390 | ||||||||
| Height of mast, lowered |
h1 (mm) | 1990 | 1991 | 2291 | 1990 | 1991 | 2291 | 1990 | 1991 | 2291 |
| Free lift | h2 (mm) | 166 | ||||||||
| Lift | h3 (mm) | 1600 | 3000 | 3600 | 1600 | 3000 | 3600 | 1600 | 3000 | 3600 |
| Height of mast, extended |
h4 (mm) | 1990 | 3408 | 4008 | 1990 | 3408 | 4008 | 1990 | 3408 | 4008 |
| Height of seat/stand-on platform |
h7 (mm) | 128 | ||||||||
| Overall height(With handle |
h14 (mm) | 1063/1440 | ||||||||
| lowered hength | h13 (mm) | 85 | ||||||||
| Overall length | l1 (mm) | 2040 | ||||||||
| Length to fork face | l2 (mm) | 890 | ||||||||
| Overall width | b1/ b2 (mm) |
808 | ||||||||
| Fork dimensions | s/e/l (mm) |
60/180/1150 | ||||||||
| Width of forks | b5 (mm) | 570/695 | ||||||||
| Min.Ground clearance |
m2 (mm) | 24 | ||||||||
| Aisle width with pallet 1000 x 1200 across forks |
Ast (mm) | 2452 | ||||||||
| Aisle width with pallet 800 x 1200 along forks |
Ast (mm) | 2432 | ||||||||
| Min.Turning radius | Wa (mm) | 1570 | ||||||||
| Travel speed,laden/unladen |
(km/h) | 5.2/5.5 | ||||||||
| Lifting speed, with/without load |
(mm/s) | 95/130 | 80/130 | 70/130 | ||||||
| Lowering speed, with/without load |
(mm/s) | 190/180 | 180/180 | 180/180 | ||||||
| Maximum climbing ability, with/without load |
(%) | 6 / 8 | ||||||||
| Service brake | Electromagnetic | |||||||||
| Drive motor, 60 minute rating |
(kW) | 1.5 | 2.5 | 2.5 | ||||||
| Lift motor rating at S3 15% |
(kW) | 3 | 3 | 3 | ||||||
| Battery voltage/rated capacity |
(V/Ah) | 24/210 | ||||||||
| Battery weight (± 5%) |
(kg) | 210 | ||||||||
| Type of drive control | AC | |||||||||
| Noise level at operator‘s ear |
(dB(A)) | ≤70 | ||||||||
| Type of steering | Electric | |||||||||
