Product Details:
Payment & Shipping Terms:
|
| Color: | Any | Weight: | 90KG |
|---|---|---|---|
| Plate Size: | 300*275mm | Force: | 17kn |
| Jumping Height: | 55-70mm | HS Code: | 8430610000 |
| High Light: | upright rammer compactor,jumping jack tamper |
||
Motor works on 380V triple phase supply.
Good for closed space or in-door use. Widely used in municipal conservation, road construction, building construction, flooring treatment(epoxy floor, wear-resistant floor) and other fields.
German made polyurethane ribbed bellow for long life. An integrated fuel valve provides for easy starting. Rammer shoe made of steel plate with wooden insert offers economical usage.
Technical Specification:
| Model | Motor | Power | Force | Rate | Speed | Jump Height | Plate Size | Weight |
| v/hz | kw | kN | time/min | m/min | mm | mm | kg | |
| HCD70 | 380/50 | 2.2 | 17 | 600-700 | 8-12 | 55-70 | 275*300 | 75 |
| HCD70B | 380/50 | 2.5 | 16 | 600-700 | 8-12 | 45-65 | 250*290 | 75 |
| HCD100 | 380/50 | 3 | 20 | 600-700 | 8-12 | 55-70 | 340*285 | 90 |
